Signal conditioners and measuring transducers

MINI MCR-BL-PT100-I-NC

MINI MCR-BL-RPS-I-I

MACX MCR-RTD-I-C

MACX MCR-EX-RTD-I-C

MACX MCR-EX-AP-2F-2I-SP

MACX MCR-TC-I-C

MACX MCR-EX-AP-2T-2I-SP

MINI MCR-BL-UI-UI

MACX MCR-EX-AP-2T-2I

MACX MCR-EX-AP-2F-2I

MINI MCR-2-IDS-I-I-PT

Output signal conditioner for isolating and transmitting 0 mA / 4 mA ... 20 mA signals from the controller to an intrinsically safe load in the Ex area. HART-transparent, no-load voltage: 27 V DC, Standard configuration, Push-in connection

MINI MCR-2-IDS-I-I

Output signal conditioner for isolating and transmitting 0 mA / 4 mA ... 20 mA signals from the controller to an intrinsically safe load in the Ex area. HART-transparent, no-load voltage: 27 V DC, Standard configuration, Screw connection

MINI MCR-EX-NAM-T

Ex i-NAMUR signal conditioner for operating proximity sensors and switches. The signals are transmitted to the control level via 1 transistor output (passive). Standard configuration, Line fault detection, Safety Integrity Level (SIL, IEC 61508): 3, Screw connection

MACX MCR-IDS-2I-2I-SP

2-channel output signal conditioner, HART-transparent. Isolates and transmits 0/4 mA ... 20 mA signals to a load in the safe area. 4-way electrical isolation, line fault detection, SIL 2 (SC3) in accordance with IEC 61508, Push-in connection.

MINI MCR-2-RPS-2I-2I-OLP

Two-channel output loop-powered 2-way repeater power supply with plug-in connection technology for the electrical isolation of analog signals. Input signal = output signal: 0(4) mA ... 20 mA. Screw connection technology.

MACX MCR-SL-UI-REL-SP

Limit value switch with input for active current and voltage signals and a limit-value relay output (changeover contact). Can be set via DIP switch and potentiometer, galvanic 3-way electrical isolation, up to SIL2 (SC3), PLc Cat.1, Push-in connection.

MACX MCR-EX-SL-UI-REL-SP

Limit value switch with Ex i input for active current and voltage signals and a limit-value relay output (changeover contact). Can be set via DIP switch and potentiometer, galvanic 3-way electrical isolation, up to SIL2 (SC3), PLc Cat.1, Push-in connection.

MACX MCR-EX-DUMMY-ISOLATOR-SP

Dummy module with no function for connecting unused intrinsically safe signal cables, with plug-in push-in connection terminal blocks.
